Low-speed Drag Chain Cable

The conductor is made of multiple strands of ultra-fine twisted oxygen-free copper wire with good flexibility. The tinned copper mesh braided shield has a shielding density of over 80% and strong anti-electromagnetic interference capability. The insulation and sheath are made of special modified elastomers, which are waterproof, oil-proof, wear-resistant, and weather-resistant. They can withstand mechanical external forces and are suitable for industrial frequent bending scenarios.

Contact Now E-Mail Telephone WhatsApp

Product Details

Product Description

TRVVP series towed chain cable is a type of shielded towed chain cable. Its conductor is made of multi-strand ultra-fine finely stranded oxygen-free copper wires. The insulation layer is made of special mixed PVC or modified elastomer material, and the sheath is generally made of specially improved PVC. The cable adopts tinned copper mesh braided shielding, with a shielding density usually over 80%, which can effectively resist electromagnetic interference. It is suitable for dry or humid indoor environments and is often used in industrial scenarios requiring frequent bending, such as woodworking machinery, machine tool processing equipment, and logistics conveying systems.

It is mainly used as a power transmission cable for long-term reciprocating movement in towed chains of equipment like machine tools, robot system integration, and industrial automation devices.

Relevant Standards:

CRIA 0003-2016 Special Cables for Industrial Robots

TICW 21 Flexible Cables for Industrial Robots

2 PfG 2577/08.16 Cable Usage Requirements for Robot Systems

Flexible Drag Chain Cable

Technical Parameters

TRVVP Series Product Structure Parameters (Rated Voltage 450/750V)

Number of Cores × Cross-Sectional Area (mm²)	Maximum Single Wire Diameter of Conductor (mm)	Core Outer Diameter (mm)	Maximum Cable Outer Diameter (mm)	Maximum DC Resistance of Conductor at 20°C (Ω/km)
4×0.75	0.15	2.1	8.4	26.0
4×1.0	0.15	2.5	9.4	19.5
4×1.5	0.15	3.0	10.6	13.3
4×2.5	0.15	3.9	12.8	7.98
6×0.75	0.15	2.1	-	26.0
6×1.0	0.15	2.5	10.8	19.5
6×1.5	0.15	3.0	12.3	13.3
6×2.5	0.15	3.9	15.0	7.98
-	0.15	-	9.7	-

TRVVP Series Product Structure Parameters (Rated Voltage 300/500V)

Number of Cores × Cross-Sectional Area (mm²)	Maximum Single Wire Diameter of Conductor (mm)	Core Outer Diameter (mm)	Maximum Cable Outer Diameter (mm)	Maximum DC Resistance of Conductor at 20°C (Ω/km)
2×0.3	0.15	1.5	5.1	69.2
2×0.5	0.15	1.7	5.5	39.0
2×0.75	0.15	2.1	6.3	26.0
3×0.3	0.15	1.5	5.3	69.2
3×0.5	0.15	1.7	5.8	39.0
3×0.75	0.15	2.1	6.7	26.0
4×0.2	0.15	-	5.0	92.3
4×0.3	0.15	1.5	5.7	69.2
4×0.5	0.15	1.7	6.6	39.0
5×0.5	0.15	1.7	6.7	39.0
6×0.5	0.15	1.7	7.6	39.0
8×0.25	0.15	1.3	6.5	87.6
8×0.5	0.15	1.7	8.4	39.0
8×0.75	0.15	2.1	9.8	26.0
12×0.3	0.15	1.5	8.7	69.2
12×0.5	0.15	1.7	9.8	39.0
12×0.75	0.15	2.1	11.7	26.0
-	0.15	-	9.5	-
16×0.3	0.15	1.5	-	69.2
16×0.5	0.15	1.7	10.9	39.0
16×0.75	0.15	2.1	13.3	26.0
19×0.5	0.15	1.7	11.5	39.0
24×0.5	0.15	1.7	13.6	39.0
25×0.5	0.15	1.7	13.8	39.0
