Cable Chain Track

The Cable Chain Track is specially designed for high-dynamic applications where continuous movement, frequent bending, and mechanical stress are common. Engineered for superior flexibility and abrasion resistance, this cable provides reliable and safe power transmission in demanding industrial environments.

Built with high-quality materials, the cable features a Class 6 fine-stranded bare copper conductor (VDE 0295 / IEC 60228), ensuring excellent conductivity and long-term durability. The insulation is made of a special elastomer compound, offering enhanced mechanical protection and resistance to oil and wear. Core identification is simplified with black number-coded wires, and cables with three or more conductors include a yellow/green ground wire for safety and compliance.

The outer sheath is made from a heat-resistant, lead-free PVC compound rated for continuous operation up to 80°C. It comes in a matte black (RAL9005) or orange (RAL2003) finish for easy visibility in industrial settings. Reinforced with a specialized exterior treatment, the sheath protects the cable from mechanical impacts and harsh environmental factors.

With a tested drag chain lifespan of over 20 million bending cycles, this cable is ideal for use in CNC machines, robotic arms, and automation systems where constant motion is required. It supports tight installation spaces with a minimum bending radius of 7.5× cable diameter for moving applications and 4× for fixed installations.

Operating temperature ranges from -5°C to 80°C in dynamic applications and -40°C to 80°C when fixed. The cable is flame-retardant (IEC60332-1) and fully RoHS compliant, ensuring safety, environmental responsibility, and performance stability over time.
